Description

Air disinfection

Equipped with the technology of the disk turning this device easy to use, efficient, allows an air disinfection of surfaces (DSVA) of surfaces in a homogeneous and complete manner. Control of infectious risks, decontamination of a place up to 180 m3 (hospitals, laboratories, pharmaceutical industry, agri-food, cosmetics, biotechnology, zootechnics and logistics, ambulances, pet shops, veterinarians, bacteriology, schools .. ) light table appliance of 6 kg.

Operation

With a rate of 800 ml/h, this vertical nebulizer table works on the sector or battery. Its diffusion is carried out by means of disk and a fan in order to spread the micro droplets by dry misting to the room to be treated . Powered by a peristaltic pump that sucks the liquid to be diffused from a 1-litre can connected to the nebulizer by a silicone hose.
Nebulizer programming takes place by adjusting the push buttons aligned near the built-in viewing screen. With these settings, the atomizer can operate continuously or by alternating broadcast and pause cycles. If the broadcast is programmed continuously, all the liquid is sprayed at once. With pauses, the liquid may last longer. To calculate the duration of spraying by air, the volume of liquid must be divided by the flow of the machine. Thus, a volume of 500 ml of liquid for 50m3 will be sprayed in 37 minutes with a device with a flow rate of 800 ml/h.

To program the utensil,simply adjust the different functions correctly.
To fix the spray cycles, there is the function C (cycles), which can be programmed from 1 to 99. Streaming is achieved by adjusting C to value1. The spraying time is obtained by adjusting the function D (duration), programmable from 0 to 99 minutes and 59 seconds. Each effective spray cycle is programmed by setting D by 1 second step. For the 500 ml volume of liquid from the previous example, 12 cycles of 3 minutes each will diffuse the entirety with the flow of 800ml/h.
The pauses between each cycle are made with the R function (delay), which is programmable from 0 to 9 hours and 59 minutes. This is the duration of the diffusion of liquid alternating with the rest time, to be programmed by 1 minute steps. With a break time of 5 minutes between each previously set 3-minute broadcast cycle, the nebulizer will start broadcasting after 5 minutes. It sprays for 3 minutes and then stops for 5 minutes again before resuming broadcasting, for a total of 1 hour 37 minutes, in order to exhaust the 500 ml of the example. For large volumes it is advisable to use the 2000 ml/h or 1400 ml/h

Other controls and functions

Equipped with an LED lamp, the nebulizer can be viewed from afar to control its proper operation. The nebulizer disk automatically shuts down when the upstream liquid presence sensor (CPL) no longer collects any liquids. The exhaustion of the contents of the can is therefore not likely to cause problems.
At the end of the scattering, the automatic draining of the hydraulic system is triggered, while the remaining unrepraund liquid is returned to the can.
The nebulizer can atomize all types of liquids, viscous or non-flammable and non-flammable,compatible with novoprene, dietary fat, 304L stainless steel, PTFE and silicone (joint).

To prevent the appearance of deposit with certain liquids, the hydraulic system must be cleaned. This cleaning is done simply by placing cleaning liquid in the hydraulic system and then programming a scattering sequence.

Concrete case operating time for 50m3:

For an 800 ml/m3machine, for example,a 20 m2 piece (about 50m3) the spray time will be 30 minutes for 400 ml of product. The calculation is: 50m3 x 8ml/m3 – 400 ml (amount of liquid to use for 50m3). For a machine 800 ml/h broadcast time is 30 minutes: 60 minutes x 400 ml – 800 ml/h – 30 minutes it will be 18 minutes for a 1400 ml/h machine. After the mist you have to let the product work. Contact time can be decreased depending on the concentration of the product, for example for 5ml/m3 the recommended time is 2 hours for 10ml/m3 it can be reduced.
